Augsts spilgts LCD skārienekrāns

Min. Pasūtījums:1 Piece/Pieces

Iepakošana un piegāde

Vienību pārdošana:

Piece/Pieces

Produkta ievads

12.1 collas LCD iegultais modulis ar augstu spilgtu. Spilgtums 1000Nits var viegli lasīt zem saules.

Augstu spilgtu LCD skārienekrānu var izmantot iekštelpās vai ārpus telpām.

touch lcd screen

touch screen

Product specification
LCD panel
Panel size	12.1"
Resolution	1024*768
Support Color	16.7M colors
Brightness (cd/m²)	1000 nits (can be customized)
Contrast ratio	1000:1
View angle	80°/80°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type	Capacitive Touch (10 points )
Surface Hardness	7H
Luminousness	90%
Touch Interface	USB (RS232 optional)
Touch response time	2ms
Working Life	>50 million times
OSD
OSD control	Brightness, contrast ratio, auto adjustment, H/V position, language select, etc.
Support languages	English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc.
Support OS	Windows ,HDMI, Android, ect.
Power Supply
External Power Supply	AC 100 - 240V, 50-60Hz
Working voltage	DC 12-24V
Power consumption	≤35W
Enclosure
Material	Aluminum Alloy
Color	Black, Silver or customized
VESA mounting	75x75mm/100x100mm
IP grade	Front panel IP55 waterproof
Operating Environment
Temperature Range	operating: -20 to 50°C, storage: -30 to 80°C
Relative humidity	operating: -5% to 95%, storage: -5% to 95%
Packing Details
Gross weight	about 4.5kg
Accessories	Power adapter, VGA cable, USB touch cable, embedded screws
Other
Mounting	embedded mounting screws
wall mounting brackets (optional)
desk stand holder (optional)
Warranty	1 year warranty
Certificates	CE, 3C, RoHS

Karstās tagi: augsts spilgts LCD skārienekrāns, Ķīna, rūpnīca, lēta, cena, pielāgots, citāts, logu vērsts LCD, viedā spoguļa ekrāns, 1500 NITS skārienjūtīgs monitors, augsts spilgts skārienekrāns, IR pieskāriena monitors, pieskāriena monitora ekrāns, 1000 NITS Touch Ekrāns , LCD panelis, LCD modulis, augsta spilgtuma displejs.
